Recommended Room Size
15 - 60 m²
100 - 600 ft²

Speaker Configuration
12 speaker drivers
2 x 1" tweeter
4 x 2.5" full-range
2 x 3"" mid-range
1 x 5.25" mid-range + 1 x 1"" tweeter for custom made coaxial centre speaker
2 x 6.5" woofer custom made

Amplifier
12 power amplifiers
10 x 60 watts amplifiers for center channel, left/right/upfiring/side firing outputs
2 x 100 watts amplifiers for bass outputs

Total: 800 W

Frequency Range
28 Hz - 23,000 Hz

Maximum Sound Pressure Level @1m
112 dB SPL

Bass Capability
94 dB SPL

Advanced Sound Features
Integrated 7.1.4 Dolby Atmos decoding and custom-tuned post-processing with proprietary
True Image up- / downmixing algorithm.
Advanced Bass management system
Adaptive Bass Linearization
Thermal protection

RoomSense
Automated speaker setup with external microphone:
Speaker level and distance
Speaker role
Speaker position compensation from 30 – 10.000Hz
Room resonance compensation from 30 – 200Hz

Sound format HDMI
Dolby Atmos supporting:
Dolby Digital TrueHD
Dolby Digital plus 7.1 (including DD5.1)
Dolby Atmos, Dolby MAT

PCM 7.1 multichannel

MPEG-2 AAC
MPEG-4 HE-AAC

Customizable Sound EQ
Presets available and fully customisable through the Bang & Olufsen App

Designer
Noto GmbH

Materials
Aluminium
Wood / Fabric
Fabric
Polymer

Dimensions
Soundbar table stand 19.7 h x 15.7 d x 122.2 w cm
Soundbar wall bracket, close position 18.9 h x 15.8 d x 122.2 w cm

Weight
18kg

Power consumption
Typical 120 W

Power
Power Cable

Bluetooth Version
Bluetooth 5.1 (BLE and EDR)

Bluetooth Codecs
Android: SBC
iOS: SBC, AAC

WiFi
Dual-Band Wi-Fi 5 (2.4 & 5 GHz)
IEEE 802.11 b/g/a/n/ac

Streaming services
Apple AirPlay
Spotify Connect
Chromecast built-in
TIDAL Connect
B&O Radio
Deezer
QPlay 2.0

Beolink Multiroom
Yes

Additional surround sound speaker connection
Yes (8 wired & 8 wireless)

Physical Connections
Soundbar inputs:
3 x HDMI input with CEC input
1 x HDMI eARC with passthrough 4K 120FPS / 8K 60FPS / 40Gbit
4 x 1Gbit Ethernet (One port assigned for LG OLED TV connection for integrated control via Beoremote One and Bang & Olufsen App)
1 x 3.5mm jack
1 x USB-C

Soundbar outputs:
8 x Wireless Powerlink
8 x Powerlink

Remote controls
Integrated system control, including LG OLED TV:
Bang & Olufsen App
Beoremote One BT
Beoremote Halo

TV remote (volume-mute-on-standby) control commands via HDMI ARC

On-Device Controls
Yes

Peripheral Unit Control
Integrated Peripheral Unit/Set-top Box Controller for two units, allowing you to control set-top boxes with the Bang & Olufsen remote control
