Recommended Room Size
10-60 m²
100-600 ft²

Speaker Configuration
12 speaker drivers
2 x 1" tweeter
4 x 2.5" full-range
2 x 3" mid-range
1 x 5.25" mid-range + 1 x 1" tweeter for custom-made coaxial center speaker
2 x 6.5" custom-made woofer

Amplifier
12 power amplifiers
10 x 60 watts amplifiers for center channel, left/right/upfiring/side firing outputs
2 x 100 watts amplifiers for bass outputs

Total: 800 W

Frequency Range
28Hz - 23,000 Hz

Advanced Sound Features
Integrated 7.1.4 Dolby Atmos decoding and custom-tuned post-processing with proprietary True Image up- / downmixing algorithm.
Advanced Bass management system
Adaptive Bass Linearization
Thermal protection

RoomSense
Automated speaker setup with external microphone:
Speaker level and distance
Speaker role
Speaker position compensation from 30 – 10,000Hz
Room resonance compensation from 30 – 200Hz

Sound Format HDMI
Dolby Atmos supporting:
Dolby Digital TrueHD
Dolby Digital plus 7.1 (including DD5.1)
Dolby Atmos, Dolby MAT

PCM 7.1 multichannel

MPEG-2 AAC
MPEG-4 HE-AAC

Customizable Sound EQ
Presets available and fully customizable through the Bang & Olufsen App.

Available Screen Sizes
55"
65"
77"

Display Type & Resolution
4K OLED
3840 x 2160, over 8M pixels

HDR
HDR 10
HDR 10 Pro
HLG
Dolby Vision IQ

Gaming
< 1 ms response time
Input lag 12.8 ms
VRR
G-sync and FreeSync™ compatible
ALLM

4K and 2K HFR
HGiG mode

Smart TV
webOS

Designer:
Noto GmbH

Materials:
Aluminium
Wood / Fabric
Fabric
Polymer

Placement options:
Motorised Floor Stand +/- 35° rotation
Motorised Wall Bracket left or right hinged with 60° max opening (55" or 65" screen)
Table stand

Dimensions (cm):
55"
Table Stand (free Stand/close to wall): 122.2 W x 35.9/26.5 D x 91.9 H cm
Motorised Wall Bracket: 122.2 W x 19.2 D x 95.9 H cm
Motorised Floor Stand: 122.2 W x 52.8 D x 118.9 H cm

65"
Table Stand (free Stand/close to wall): 144.1 W x 35.9/26.5 D x 104.3 H cm
Motorised Wall Bracket: 144.1 W x 19.2 D x 108.3 H cm
Motorised Floor Stand: 144.1 W x 52.8 D x 131.3 H cm

77"
Table Stand (free Stand/close to wall): 171.2 W x 35.9/26.5 D x 120.5 H cm
Motorised Floor Stand: 171.2 W x 52.8 D x 147.4 H cm
*TV screen height and width may vary depending on TV model

Weight:
55"
Table Stand incl. LG G3 TV: 49 kg
Motorised Wall Bracket incl. LG G3 TV: 62 kg
Motorised Floor Stand incl. LG G3 TV: 69 kg

65"
Table Stand incl. LG G3 TV: 53 kg
Motorised Wall Bracket incl. LG G3 TV: 68 kg
Motorised Floor Stand incl. LG G3 TV: 73 kg

77"
Table Stand incl. LG G3 TV: 66 kg
Motorised Floor Stand incl. LG G3 TV: 87 kg

Power Consumption
Typical: 120 W (Soundbar)

Power
100-240V 50/60Hz mains cable

Energy Efficiency Class
G

Bluetooth Version:
Bluetooth 5.1 (BLE and EDR)

Bluetooth Codecs:
Android: SBC
IOS: AAC, SBC

Wi-Fi:
Dual-Band Wi-Fi 5 (2.4 & 5 GHz)
IEEE 802.11 b/g/a/n/ac

Streaming services:
Apple AirPlay
Spotify Connect
UPnP
Chromecast built-in
TIDAL Connect
B&O Radio
Deezer
QPlay 2.0

Beolink Multiroom
Yes

Additional surround sound speaker connection:
Yes (8 wired & 8 wireless)

Physical Connections:
Soundbar inputs:
3 x HDMI input with CEC input
1 x HDMI eARC with passthrough 4K 120FPS / 8K 60FPS / 40Gbit
4 x 1Gbit Ethernet (One port assigned for LG OLED TV connection for integrated control via Beoremote One and Bang & Olufsen App)
1 x 3.5mm jack
1 x USB-C

Soundbar outputs:
8 x Wireless Powerlink
8 x Powerlink

Remote controls:
Integrated system control, including LG OLED TV:
Bang & Olufsen App
Beoremote One BT
Beoremote Halo

On-Device Controls:
Yes

Peripheral Unit Control:
Integrated Peripheral Unit/Set-top Box Controller for two units, allowing you to control set-top boxes with the Bang & Olufsen remote control.
